SPIRE II Series – Installation and Operating Instructions
Page 7-2
t
rouBleshootInG
Symptom Possible Cause Corrective Action
LCD does not illuminate
on the control panel when
the ON/OFF switch is in the
ON position. Laminator not connected to electrical
supply. Insert attachment plug into receptacle.
Blown fuse. Replace fuse or contact your dealer or
distributor for assistance.
Rollers do not turn. Photo Safety Sensors blocked. Unblock Photo Safety Sensors.
Feed Table Interlock Latch not in place. Reseat Interlock Latch all the way down
until the micro switch activates.
STOP LED flashing. Press STOP.
Laminated items are
curling. Tension between the top and bottom film
roll is unequal. Adjust tension per “Film Tension” section..
Speed setting too slow. Slightly speed up laminator.
Adhesive deposited on
rollers. Top and bottom film webs not aligned. Align film webs per “Film Alignment”
section.
Laminate improperly loaded. Load film per “Loading Film” section.
Unsatisfactory laminate
adhesion. Insufficient roller pressure. Adjust the roller pressure.
Laminate improperly loaded. Load film per procedure outlined per
“Loading Film” section.
Rollers require cleaning. Clean rollers per Cleaning the Rollers
section.
Laminated item unsuitable for adhesion. Item may be dirty or may have
non-porous surface that is extremely
difficult to laminate.
