SPIRE II Series – Installation and Operating Instructions
Page 6-12
t
Ips
For
c
ustom
a
pplIcatIon
#2
Rewinder
Idler
Idler
Idler
Main
Roller
Main
Roller
Supply
Shaft
Supply
Shaft
Figure 47. Custom application 2.
1.
2.
3.
4.
t
Ips
For
c
ustom
a
pplIcatIon
#3
Rewinder
Idler
Idler
Idler
Main
Roller
Main
Roller
Supply
Shaft
Supply
Shaft
Figure 48. Custom application 3.
1.
2.
3.
4.
F
Ilm
a
lIGnment
The top and bottom supply rolls must be aligned
as closely as possible. Misalignment can cause
adhesives to stick to the rollers. The 3 inch Extruded
and AUTOGRIP Shafts have rulers incorporated to
assist centering the film on the shafts.
Figure 49. Measuring rules on Shafts to align the rolls.
To align the supply rolls:
1. With the film roll on the shaft, note the
measurement on each end of the shaft.
2. Shift the roll side to side to ensure that the two
measurements are equal.
