2 E-flite P-40 Warhawk Assembly Manual
Product Registration
Register your product online at:
www.e-fliterc.com/register/
Contents of Kit/Parts Layout
EFL6076 Fuselage with Tail and Hatch
EFL6077 Main Wing
EFL6078 Propeller (2)
EFL6079 Spinner
EFL6080 Motor
EFL6081 Canopy Hatch
EFL6082 Wing Mount O-rings (3)
EFL6083 Horizontal Stabilizer
Introduction
Thank you for purchasing the E-flite ® P-40 Warhawk
300 ARF. On paper, the P-40 was outclassed by many
of the foes it faced. But in the hands of the pilots of the
American Volunteers Group, the Warhawk was used
to deadly effect against “superior” Zeros. Their exploits
made the iconic shark-toothed grin of the “Flying
Tigers” a symbol of victory for the Allies and cause for
concern to any enemy pilot that encountered it.
E-flite has captured the spirit of the Tigers in this fun-
to-fly recreation of the P-40 that goes together fast
and is small enough to fly in the park. It comes out
of the box loaded with scale details like an authentic
Flying Tigers paint scheme and molded panel lines. It
also comes equipped with a factory-installed 300 BL
outrunner motor that will provide plenty of power for
warbird aerobatics like loops, rolls and Immelmans. Its
simple 3-channel control setup means you only need to
buy two servos – one for aileron and one for elevator
– making it even more affordable to get flying. When
you’re not flying, you can show off its scale looks with
included static display stand.
Important Warranty Information
Please read our Warranty and Liability Limitations
section on Page 14 before building this product. If you
as the Purchaser or user are not prepared to accept the
liability associated with the use of this Product, you are
advised to return this Product immediately in new and
unused condition to the place of purchase.
Using the Manual
This manual is divided into sections to help make
assembly easier to understand, and to provide breaks
between each major section. In addition, check boxes
have been placed next to each step to keep track of its
completion.
Remember to take your time and follow the directions.
Table of Contents
Introduction ........................................................... 2
Important Warranty Information .............................. 2
Using the Manual ................................................... 2
Product Registration................................................ 2
Contents of Kit/Parts Layout .................................... 2
Recommended Radio Equipment ............................. 3
Additional Electronics ............................................. 3
Optional Accessories .............................................. 3
Required Tools and Adhesives ................................. 3
Note on Lithium Polymer Batteries ........................... 3
Electronics Installation ............................................. 3
Linkage Connections ............................................... 6
Wing Installation .................................................... 8
Battery Installation .................................................. 9
Spinner Installation ................................................. 9
Propeller Removal and Replacement ...................... 10
Display Stand Assembly ....................................... 11
Control Throws..................................................... 12
Center of Gravity ................................................. 13
Preflight ............................................................... 13
Range Test Your Radio .......................................... 14
Flying Your P-40 Warhawk ................................... 14
Safety Do’s and Don’ts for Pilots ............................ 14
Age Requirements ................................................ 14
Safety, Precautions and Warnings ......................... 15
Warranty Information ........................................... 15
CE Compliance Information for the
European Union .............................................. 17
2009 Official Academy of
Model Aeronautics Safety Code ....................... 17
Declaration of Conformity ..................................... 18
