Watts 629 203C - Manual

Series 629
Cast Brass Grid Drains
Features
• cast brass body and tailpiece
• chrome plated finish
• 1 1 ⁄
4
" x 6" T.O.E. Brass Tube
(Threaded One End) 17GA.
For Commercial Applications
ES-WB&T-629
Job Name ––––––––––––––––––––––––––––––––––––––––––– Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location ––––––––––––––––––––––––––––––––––––––––– Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer ––––––––––––––––––––––––––––––––––––––––––––– Contractor’s P.O. No. –––––––––––––––––––––––––––––––––––
Approval ––––––––––––––––––––––––––––––––––––––––––––– Representative ––––––––––––––––––––––––––––––––––––––––
PRODUCT SUBMITTAL
✔ To
Model # Submit QTY
629203C
ES-WB&T-629 0329 © Watts Brass & Tubular 2001 Printed in U.S.A.
100 Watts Road • Spindale, NC 28160
Tel: (828) 286-4151 Fax: (828) 286-0729
www.wattsbrass-tubular.com
Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise
measurements, please contact Watts Technical Service. Watts reserves the right to change or modify product design, construc-
tion, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications
on Watts products previously or subsequently sold.
Series 629203C
MODEL DESCRIPTION DIMENSIONS
A B
in mm in mm
629203C cast brass grid drain 2 1 ⁄ 4
57 8 1 ⁄ 4
210
