Watts 667 303B - Manual

This Package contains:
1. Two 27" “L” Section
2. One 40" Straight Tube
3. One 53" Straight Tube
4. Two End Loops with screws
fi xed to item #3.
5. One 24" Ceiling Support Rod
Two Trim Bags consisting of:
6. a) Two Shallow Flanges
b) Four Wood Screws
7. a) One Ceiling Support Flange
b) One Ceiling Support Loop
c) Two Sheet Metal Screws
Installation Instructions
1. Slip Ceiling Support Loop (7b) onto the 40" Straight Tube (2)
2. Insert swaged end of “L” sections (1) into ends of 40" Straight Tube (2).
3. Insert straight end of “L” sections thru the two End Loops (4) of the 53"
Straight Tube (3). Allow the “L” sections (1) to protrude 1" beyond the End
Loops (4) and secure in place with the set screws provided in the Loops.
4. Slip on the two Shallow Flanges (6a) onto the protruding ends of the “L”
sections, with light pressure.
Note: Bottom of Flanges (6a) must be fl ush with ends of protruding tubes.
5. Thread in the 24" Ceiling Support Rod (5) into the Ceiling Support Flange
(7a) and into the Ceiling Support Loop (7b).
6. Lift complete “D” Bar assembly up until Ceiling Support Flange (7a)
touches ceiling. Secure Ceiling Support Flange to the ceiling by using 2
Sheet Metal Screws (7c) provided in the trim kit.
7. Align Shallow Flanges (6a) to the wall so that “D” Bar Assembly is perfectly
horizontal.
8. Secure Shallow Flanges to the wall by using 4 Wood Screws (6b) provided
in the trim kit.
1" x 4
1 /
2 Ft. “D” Bar
4 Piece with Support Rod
Model #
667303B
Model # 667303B
0140472
Model #
667303B
(7c)
(7a)
(6a)
(4)
(1)
(7b)
(5)
(2)
(1)
(4)
(6b)
(6a)
(3)
Edp# 1916042
IS-667303B
0904
100
W
atts Road
•
Spindale,
NC 28160
1" x 4 1 /
2
Ft. “D” Bar
4 Piece with Support Rod
100 Watts Road • Spindale, NC 28160
