Watts LF3836BSS User Manual
Quick'n easy, Lead free, Braided stainless steel & nylon faucet connectors

Quick'N Easy
®
Braided Stainless Steel & Nylon
Faucet Connectors
Features
• Available in 12", 16", 20", 30" and 36"
(305, 406, 508, 762 and 914mm) lengths
• NSF & IAPMO Listed
Pressure – Temperature
Maximum Temperature: Stainless Steel: 180ºF (82ºC)
Nylon: 140ºF (60ºC)
Maximum Pressure: 125psi (8.75 bar)
For Commercial & Residential Applications
ES-WBT-LFFlxblCnctrs-Faucet
Job Name –––––––––––––––––––––––––––––––––––––––––––
Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location –––––––––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer –––––––––––––––––––––––––––––––––––––––––––––
Contractor’s P.O. No. ––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Representative ––––––––––––––––––––––––––––––––––––––––
Stainless Steel
A
Nylon
A
*The wetted surface of this product contacted by consumable
water contains less than 0.25% of lead by weight.
LEAD FREE
*
Model
4
to SubMit
deScriptioN
diMeNSioNS
brAid MAteriAl
A
in. mm
LF3812BSS
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
12
305
Stainless Steel
LF3812B
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
12
305
Nylon
LF3816BSS
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
16
406
Stainless Steel
LF3816B
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
16
406
Nylon
LF3820BSS
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
20
508
Stainless Steel
LF3820B
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
20
508
Nylon
LF3830BSS
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
30
762
Stainless Steel
LF3836BSS
3
⁄
8
" OD Compression x
1
⁄
2
" Faucet Connection
36
914
Stainless Steel
LF2212BSS
1
⁄
2
" OD Compression x
1
⁄
2
" Faucet Connection
12
305
Stainless Steel
LF2216BSS
1
⁄
2
" OD Compression x
1
⁄
2
" Faucet Connection
16
406
Stainless Steel
LF2220BSS
1
⁄
2
" OD Compression x
1
⁄
2
" Faucet Connection
20
508
Stainless Steel
LF2220B
1
⁄
2
" OD Compression x
1
⁄
2
" Faucet Connection
20
508
Nylon
LF1212BSS
1
⁄
2
" FIPS x
1
⁄
2
" Faucet Connection
12
305
Stainless Steel
LF1216BSS
1
⁄
2
" FIPS x
1
⁄
2
" Faucet Connection
16
406
Stainless Steel
LF1220BSS
1
⁄
2
" FIPS x
1
⁄
2
" Faucet Connection
20
508
Stainless Steel
LF1230BSS
1
⁄
2
" FIPS x
1
⁄
2
" Faucet Connection
30
762
Stainless Steel
LF3812SSD
3
⁄
8
" OD Compression x
3
⁄
8
" copper tube Delta connector
12
305
Stainless Steel
LF3820SSD
3
⁄
8
" OD Compression x
3
⁄
8
" copper tube Delta connector
20
508
Stainless Steel
LF3812WSS
3
⁄
8
" OD Compression x
3
⁄
8
" OD Compression
12
305
Stainless Steel
LF3820WSS
3
⁄
8
" OD Compression x
3
⁄
8
" OD Compression
20
508
Stainless Steel
