Watts 603 202DK - Manual

Disposer Waste
Features
• Chrome finish
• 20 Gauge brass
• Cast brass baffle tee
For Commercial & Residential Applications
ES-WBT-603_202DK
Job Name ––––––––––––––––––––––––––––––––––––––––––– Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location ––––––––––––––––––––––––––––––––––––––––– Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer –––––––––––––––––––––––––––––––––––––––––––– Contractor’s P.O. No. ––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––– Representative ––––––––––––––––––––––––––––––––––––––––
MODEL DESCRIPTION ✓ ✓ TO SUBMIT DIMENSIONS FINISH
A B C D
in. mm in. mm in. mm
603 202DK 1 1 / 2 w/cast tee 14 356 12 305 1 1 / 2 38 20 Ga. Chrome
Series 603 202DK
A
D
D
D
C
C
C
B
ES-WBT-603_202DK 1015 © 2010 Watts
USA: 815 Chestnut St., No. Andover, MA 01845-6098; www.watts.com
Canada: 5435 North Service Rd., Burlington, ONT. L7L 5H7; www.wattscanada.ca A Watts Water Technologies Company
Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements, please contact Watts Technical Service. Watts
reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications
on Watts products previously or subsequently sold.
603 202DK
