DIMENSIONAL DRAWING — ROOF CURB, 558D090-150
ROOF CURB
ACCESSORY
‘‘A’’
UNIT SIZE
558D
CRRFCURB003A00 1 Ј -2 Љ [356]
090-150
CRRFCURB004A00 2 Ј -0 Љ [610]
SERVICE PLATE SIZES
UNIT SIZE
558D
‘‘B’’ ‘‘C’’
‘‘D’’ ALT
DRAIN
HOLE
POWER CONTROL
CONNECTOR
PKG ACY
090-150
2 Ј -8 7 ⁄ 16
Љ
[827]
1 Ј -10 15 ⁄ 16
Љ
[583]
1 3 ⁄ 4
Љ [45]
3 ⁄
4
Љ NPT 1 ⁄
2
Љ NPT
CRBTMPWR001A00*
(THRU-THE-BOTTOM)
1 1 ⁄ 4
Љ NPT 1 ⁄ 2
Љ NPT
CRBTMPWR002A00*
(THRU-THE-BOTTOM)
*Either connector package available for either roof curb.
NOTES:
1. Roof curb accessory is shipped unassembled.
2. Insulated panels.
3. Dimensions in [
] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on curb).
6. Service clearance 4 ft on each side.
7. Direction of airflow.
