IMPORTANT: INQUIRE WITH GOVERNING AUTHORITIES
FOR LOCAL INSTALLATION REQUIREMENTS
Leak Sensor
Used in conjunction with the A2C-M1 or A2C-WB-M1, the leak
sensor provides the maximum level of protection. Should water be
detected at the leak sensor at any time, the water flow to the wash-
ing machine hoses will be cut off immediately. This protects against
catastrophic water damage regardless of the operating cycle of the
washing machine.
Optional Accessories
A2-IntelliTimer: A remote timer which allows the IntelliFlow
®
to
be used with 240VAC powered appliances. Request literature
ES/IS-A2-IntelliTimer.
Construction
The Watts No. A2C-M1 is equipped with
1
⁄
2
" (13mm) sweat inlet adapters
for both hot water and cold water supply tubing. It is supplied with two
mounting tabs used to secure the valve to the wall for surface mount appli-
cations. The valve is enclosed in an engineered polymer enclosure.
Easy Installation
The Watts A2C-M1 IntelliFlow
®
comes equipped with
1
⁄
2
" (13mm)
sweat adapters to receive tubing. Either connection may be used
for the hot or cold water supply because the A2C-M1 is equipped
with long wearing Buna-N diaphragms for long life.
Water supply connections are 2
3
⁄
8
" (60mm) on centers.
No electrical wiring is required. Simply plug the washing machine
power cord into the IntelliFlow
®
and plug it to the standard 15A,
GFI†, 120 volt outlet.
†Ground fault interrupter circuit
Dimensions — Weights
Model A2C-M1
For surface mounting or
retrofit installation
(See S-ES-A2-K)
Model A2C-WB-M1
For Recessed Wall Mounting
CAUTION: Use of the Watts Automatic Washing
Machine Valve outlet for appliances other than a
washing machine is not recommended and voids
the warranty.
Note: This valve cannot be used for 240 VAC,
3 phase appliances.
Leak Sensor
Typical Installations
The Watts IntelliFlow
®
can be installed in new construction or as an
upgrade to existing installations.
Model A2C-WB-M1
Model A2C-M1
C
D
B
E
A
D
B
E
A
MODEL
SIZE (DN)
DIMENSIONS
WEIGHT
A
B
C
D
E
in.
mm
in.
mm
in.
mm
in.
mm
in.
mm
in.
mm
lbs.
kg
A2C-M1
1
⁄
2
15
6
152
2
1
⁄
8
54
4
1
⁄
4
108
3
1
⁄
32
77
2
3
⁄
8
60
2.0
.9
A2C-M1-WB
1
⁄
2
15
8
1
⁄
2
216
2
1
⁄
8
54
4
1
⁄
4
108
3
1
⁄
32
77
2
3
⁄
8
60
3.5
1.6
11
3
⁄
4
" (298mm)
7"
(178mm)
10
5
⁄
32
"
(258mm)
8
9
⁄
16
" (217mm)
C
ES-A2C-M1 0927
