For Commercial & Residential Applications
ES-WB&T-FCP
Job Name ––––––––––––––––––––––––––––––––––––––––––– Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location ––––––––––––––––––––––––––––––––––––––––– Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer ––––––––––––––––––––––––––––––––––––––––––––– Contractor’s P.O. No. –––––––––––––––––––––––––––––––––––
Approval ––––––––––––––––––––––––––––––––––––––––––––– Representative ––––––––––––––––––––––––––––––––––––––––
ES-WB&T-FCP 0535 © Watts Brass and Tubular, 2005
815 Chestnut St., No. Andover, MA 01845
www.wattsbrass-tubular.com
B
A
Floor and Ceiling Plates
Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements,
please contact Watts Technical Service. Watts reserves the right to change or modify product design, construction, specifications, or materials with-
out prior notice and without incurring any obligation to make such changes and modifications on Watts products previously or subsequently sold.
MODEL TO SUBMIT DESCRIPTION DIMENSIONS FINISH
A B
in. mm in. mm
16 0BA 3 /
8
" IPS 11 /
16
17 2 7 /
8
73 Chrome
16 1BA 1 /
2
" IPS 13 /
16
21 3 13 /
16
97 Chrome
16 2BA 3 /
4
" IPS 1 1 /
16
27 2 7 /
8
73 Chrome
16 3BA 1" IPS 1 5 /
16
33 3 5 /
8
92 Chrome
16 4BA 1 1 /
4
" IPS 1 11 /
16
43 3 5 /
8
92 Chrome
16 5BA 1 1 / 2 " IPS 1 7 / 8 48 3 5 / 8 92 Chrome
16 6BA 2" IPS 2 3 /
8
60 4 9 /
16
116 Chrome
16 7BA 1 /
2
" Copper 5 /
8
16 2 13 /
16
71 Chrome
16 8BA 3 /
4
" Copper 7 /
8
22 2 7 /
8
73 Chrome
16 9BA 1" Copper 1 1 /
8
29 2 7 /
8
73 Chrome
16 10BA 1 1 /
4
" Copper 1 3 /
8
35 3 9 /
16
90 Chrome
16 11BA 1 1 / 2 " Copper 1 5 / 8 41 3 9 / 16 90 Chrome
