Series 515, Milwaukee style utility traps, For commercial & residential applications

Milwaukee Style Utility Traps
Features
• Available with or without cleanout
• Available in 17 gauge or 20 gauge
• Includes deep bell escutcheon for wall tube
For Commercial & Residential Applications
ES-WB&T-515
Job Name ––––––––––––––––––––––––––––––––––––––––––– Contractor
––––––––––––––––––––––––––––––––––––––––––––
Job Location ––––––––––––––––––––––––––––––––––––––––– Approval
–––––––––––––––––––––––––––––––––––––––––––––
Engineer ––––––––––––––––––––––––––––––––––––––––––––
Contractor’s P.O. No. ––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––– Representative
––––––––––––––––––––––––––––––––––––––––
MODEL
DESCRIPTION
✓
TO SUBMIT CLEANOUT
DIMENSIONS
FINISH
A B C
D
E F G
in. mm
Y/N
in. mm in. mm in. mm in. mm in. mm in. mm
515 403
1
1
/
2
x 1
1
/
4
40 x 32
No
14
11
/
16
373 5
13
/
16
147 1
1
/
2
38
20
Ga.
3
1
/
2
89 11
5
/
16
287 1
13
/
16
46 Chrome
515 471
1
1
/
2
x 1
1
/
4
40 x 32
No
14
11
/
16
373 5
13
/
16
147 1
1
/
2
38
17
Ga.
3
1
/
2
89 11
5
/
16
287 1
13
/
16
46
Rough
Brass
515 473
1
1
/
2
x 1
1
/
4
40 x 32
No
14
11
/
16
373 5
13
/
16
147 1
1
/
2
38
17
Ga.
3
1
/
2
89 11
5
/
16
287 1
13
/
16
46 Chrome
515 603
1
1
/
2
x 1
1
/
4
40 x 32
Yes
14
11
/
16
373 6
3
/
16
157 1
1
/
2
38
20
Ga.
3
1
/
2
89 11
5
/
16
287 1
13
/
16
46 Chrome
515 673
1
1
/
2
x 1
1
/
4
40 x 32
Yes
14
11
/
16
373 6
3
/
16
157 1
1
/
2
38
17
Ga.
3
1
/
2
89 11
5
/
16
287 1
13
/
16
46 Chrome
Series 515
515 673
515 403
515673
A
E
F
C
D
G
B
515403
A
E
F
C
D
G
B
ES-WB&T-515 0822
© Watts, 2008
USA: 815 Chestnut St., No. Andover, MA 01845-6098; www.watts.com
Canada: 5435 North Service Rd., Burlington, ONT. L7L 5H7; www.wattscanada.ca
B r a s s & T u b u l a r P r o d u c t s
Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements, please contact Watts Technical Service. Watts
reserves the right to change or modify product design, construction, specifications, or materials without prior notice and without incurring any obligation to make such changes and modifications
on Watts products previously or subsequently sold.
