Watts Jumbo Plastic Housing - Manual (Page 4)

Pressure Drop
pressure Drop (psi)
0 25 50 100 125 150
1 Abs.
15
10
5
Flow (Gpm)
1 µm
5 µm
20 µm
50 µm
150 µm
Low Pressure Drop
Watts ® Jumbo Cartridge Housings are designed to minimize pressure
drop, by using 2" pipe fittings and large diameter center tubes .
(See chart above for pressure drop data using pleated cartridges .)
