R55F Series Fiber-Optic Color Mark Sensors
page 11
Banner Engineering Corp. • Minneapolis, U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
R55F Series Sensor Hookups
bn
wh
bu
+
–
bk
Load
Load
10-30V dc
Remote Teach
gy
bn
wh
bu
+
–
bk
Load
Load
10-30V dc
Remote Teach
gy
Cabled Models Quick-Disconnect Models
Mounting Brackets
Both brackets are included with sensor.
SMBR55FRA
• Side-mounting bracket
• 19 ga stainless steel
SMBR55F01
• Flat-mounting bracket
• Molded PBT polyester
2x ø5.4 mm
(0.21")
4.5 mm
(0.18")
4.5 mm
(0.18")
2.5 mm
(0.10")
10.0 mm
(0.40")
7.5 mm
(0.30")
20.0 mm
(0.79")
35.0 mm
(1.38")
40.0 mm
(1.58")
3.5 mm
(0.14")
4x R2.5
(0.10")
4x 5.0 mm
(0.20")
29.5 mm
(1.16")
15.0 mm
(0.59")
7.2 mm
(0.28")
6.0 mm
(0.24")
35.0 mm
(1.40") 50.8 mm
(2.00")
65.0 mm
(2.56")
64.0 mm
(2.52")
50.8 mm
(2.00")
30.4 mm
(1.20")
Quick-Disconnect (QD) Cables
5-Pin Euro
MQDC1-506
MQDC1-515
MQDC1-530
MQDC1-506RA
MQDC1-515RA
MQDC1-530RA 2 m (6.5')
5 m (15')
9 m (30')
2 m (6.5')
5 m (15')
9 m (30')
Style Model Length Connector
Straight
Straight
Straight
Right-angle
Right-angle
Right-angle
White Wire
Blue Wire
Black Wire
Brown Wire
Gray Wire
