M-GAGE ™ S18M —
Vehicle Detection Sensor
Banner Engineering Corp., 9714 Tenth Ave. No., Minneapolis, MN USA 55441 • Phone: 763.544.3164 • www.bannerengineering.com • Email: [email protected]
P/N 114430 rev. C
Accessories
bn
Remote Program
bu
wh
bk
gy
+
10 - 30V dc
–
Load
Load 100 mA max. load
Shield
bn
Shield
Remote Program
bu
wh
bk
gy
+
10 - 30V dc
–
Load
Load 100 mA max. load
Cabled Model Quick-Disconnect Model
Hookups
White Wire
Blue Wire
Black Wire
Brown Wire
Gray Wire
Pin-out
Pin-Out
Model Description
SMP1
Conduit Plug for ¾" flexible conduit,
used for below-grade installations
SMP2
Conduit Plug for ¾" rigid conduit, used
for above-grade installations
DPB1
Handheld Portable Programming Box,
used for configuring sensor when
push button is not accessible
Quick-Disconnect Cables
Style Model Length Connector Style Model Length Connector
5-Pin
Euro,
Straight
with
shield
MQDEC2-506
MQDEC2-515
MQDEC2-530
2 m (6.5')
5 m (15')
9 m (30')
5-Pin
Euro,
Right-
angle
with
shield
MQDEC2-506RA
MQDEC2-515RA
MQDEC2-530RA
2 m (6.5')
5 m (15')
9 m (30')
PC
IR
O U T P U T
R E M O T E
PROGRAM TEACH
POR
T ABLE
PROGRAMMING BOX
15-24 VDC
COMM. ACTIVE POWER
N P N P N P
A
B
C
D
+ SENSOR VOL
T AGE
-
24.1 mm
(0.95")
26.2 mm
(1.03")
Ø 33.0 mm
(1.30")
38.1 mm
(1.50")
M12 x 1
ø 15 mm
44 mm
max.
Euro Straight
38 mm
max.
M12 x 1
ø 15 mm
Euro RA
38 mm
max.
Warranty: Banner Engineering Corporation warrants its products to be free from defects for a period
of one year. Banner Engineering Corporation will repair or replace, free of charge, any product of its
manufacture found to be defective at the time it is returned to the factory during the warranty period.
This warranty does not cover damage or liability for the improper application or installation of Banner
products. This warranty is in lieu of any other warranty either expressed or implied.
