SL0 Series Slot Sensor
WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering Corp. will repair or
replace, free of charge, any product of its manufacture found to be defective at the time it is returned to the factory during the warranty peri-
od. This warranty does not cover damage or liability for the improper application of Banner products. This warranty is in lieu of any other war-
ranty either expressed or implied.
Banner Engineering Corp., 9714 Tenth Ave. No., Minneapolis, MN 55441 • Phone: 888.373.6767 • http://www.baneng.com • E-mail: [email protected]
Accessories
Quick-Disconnect Cables
M12 x 1
ø 15 mm
(0.6")
38 mm max.
(1.5")
38 mm max.
(1.5")
The following cables are available for SL0 Series Slot Sensor QD models
Style Model Length Dimensions
5-pin
Euro-style
straight
MQDC1-506
MQDC1-515
MQDC1-530 2 m (6.5')
5 m (15')
9 m (30')
M12 x 1
ø 15 mm
(0.6")
44 mm max.
(1.7")
White Wire
Blue Wire
Gray Wire
Black Wire
Brown Wire
Pin-out
5-pin
Euro-style
right-angle
MQDC1-506RA
MQDC1-515RA
MQDC1-530RA 2 m (6.5')
5 m (15')
9 m (30')
Mounting Brackets
SMBSL
• Angled bracket
• 304 stainless steel
6.4 mm
(0.25")
10.2 mm
(0.40")
10.9 mm
(0.43")
30.1 mm
(1.19")
40.0 mm
(1.58")
6x ø5.5mm
(0.22")
12x R2.5mm
(0.10")
8.9 mm
(0.35")
10.9 mm
(0.43")
30.4 mm
(1.20")
6.0 mm
(0.24")
39.9 mm
(1.58")
6.0 mm
(0.24")
51.9 mm
(2.05")
7.6 mm
(0.30")
21.6 mm
(0.85")
19.1 mm
(0.75")
41.3 mm
(1.62")
