Style Model Length Dimensions Pinout
8-Pin Euro-Style
Cables with Open-
Shield
MQDC2S-806
MQDC2S-815
MQDC2S-830 2 m (6.5’)
5 m (15’)
9 m (30’)
Female
1 = White 5 = Gray
2 = Brown 6 = Pink
3 = Green 7 = Blue
4 = Yellow 8 = Red
8-Pin 7-Wire Euro
5
4
3 2
8
1
7
6
M12 x 1
ø 15 mm
44 mm
max.
Euro Straight
Accessories
Quick-Disconnect (QD) Cables
