EZ-LIGHT ™ Indicators - 5-Color, Multi-Function
2
P/N 131413 rev. A
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Specifications
Supply Voltage and Current 18 to 30V dc @ 50 mA max.
Indicators LEDs are independently selected: Green, Red, Yellow, Blue or White, ON steady or flashing, alternating or
rotating
Input Response Time Indicator ON: 250 ms (max.); Indicator OFF: 10 ms (max.)
Indicator Flash Rate 1-Color: 1 second flash rate (500 ms ON)
2, 3 and 5-Color Flash: 500 ms per color
Environmental Rating K50L and K50FL Models: Fully encapsulated, IEC IP67
K80L Models: IEC IP67 (encapsulated electronics)
Connections Integral 8-pin Euro-style QD, 150 mm PVC pigtail with QD, or 2 m (6.5’) integral cable, depending on model
K80L Models: Terminal-wired models for use with bulk cable available
Operating Conditions −40° to +50° C (−40° to +122° F)
Certifications
Percent of Maximum Intensity vs Viewing Angle
100.0%
90.0%
80.0%
70.0%
60.0%
50.0%
40.0%
30.0%
20.0%
10.0%
0.0%
-90 -80 -70 -60 -50 -40 -30 -20 -10 0 10 20 30 40 50 60 70 80 90
Intensity (Percent)
Viewing Angle (Deg)
