Q25 Sensors – ac-Voltage Series
6
P/N 121517
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Dimensions
bn
bu
bk
20-250V ac
Load
12.7 mm
(0.50")
Green LED
Power Indicator
Yellow LED
Output Indicator
Cabled Models QD Models
Cabled Emitters
25.0 mm
(0.98")
35.0 mm
(1.38")
30.0 mm*
(1.18")
12.4 mm
(0.49")
(Jam Nut Supplied)
Lens Centerline
15.2 mm
(0.60")
M18 x 1 Thread
2 m (6.5') Cable
*Fixed-field models = 31.0 mm (1.22")
20-250V ac
No Connection
rd/wh
rd/bk
rd
gn
bn
bu
20-250V ac
All Other Cabled Models
QD Emitters
(4-pin Micro-Style)
All Other QD Models
(4-pin Micro-Style)
20-250V ac
No Connection
Load
rd/wh
rd
rd/bk
gn
Hookups
