Opposed Mode
5 m
16 ft
10 m
33 ft
15 m
49 ft
0 20 m
66 ft
0
20 in
20 in
Distance
Q85 Series
opposed mode sensors
25 m
82 ft
10 in
10 in
250 mm
250 mm
500 mm
500 mm
0
1000
100
10
1
.1 m
.33 ft
1 m
3.3 ft
10 m
33 ft
Q85 Series
opposed mode
sensors
E
X
C
E
S
S
G
A
I
N
DISTANCE
23 m
75 ft
Beam Pattern Excess Gain Curve
Sensing range: 10 inches (250 millimeters)
referenced to a 90% reflectance white test card
Sensing beam: 880 nanometers, infrared
Models (short-range diffuse):
Q85BW13D (p/n 35576) no timing logic
optically-isolated SPST solid-state switch;
response time 4 milliseconds "on", 4 milliseconds "off"
repeatability 1 millisecond
Q85BW13D-T9 (p/n 35575) with timing logic
optically-isolated SPST solid-state switch;
response time 10 milliseconds "on", 10 milliseconds "off"
repeatability 1 millisecond (with no timing in use)
Polarized Retroreflective Mode
1 m
3.3 ft
2 m
6.6 ft
3 m
9.9 ft
0
4 m
13 ft
0
Distance to retroreflector
Q85 Series
polarized retro sensors
with BRT-3 3" reflector
5 m
16 ft
25 mm
50mm
75 mm 3 in
2 in
1 in
75 mm
50mm
25 mm 1 in
2 in
3 in
Beam Pattern Excess Gain Curve
1000
100
10
1
.01 m .1 m
.33 ft
1 m
3.3 ft
Q85 Series polarized
retroreflective sensors
E
X
C
E
S
S
G
A
I
N
DISTANCE TO RETROREFLECTOR
with BRT-3 3" reflector
4.6 m
15 ft
Sensing range: 39 inches (1 meter)
referenced to a 90% reflectance white test card
Sensing beam: 880 nanometers, infrared
Models (long-range diffuse):
Q85BW13DL (p/n 35568) no timing logic
optically-isolated SPST solid-state switch;
response time 4 milliseconds "on", 4 milliseconds "off"
repeatability 1 millisecond
Q85BW13DL-T9 (p/n 35567) with timing logic
optically-isolated SPST solid-state switch;
response time 10 milliseconds "on", 10 milliseconds "off"
repeatability 1 millisecond (with no timing in use)
1000
100
10
1
10 mm
.4 in
100 mm
3.9 in
250 mm
10 in
Q85 Series short-range
diffuse mode sensors
E
X
C
E
S
S
G
A
I
N
DISTANCE
Range is referenced
to a 90% reflectance
white test card
Beam Pattern
50mm
2 in
100mm
4 in
150mm
6 in
0
0
25 mm
25 mm
Distance to 90% white test card
Q85 Series
short-range diffuse sensors
250mm
10 in
2 in
2 in
200mm
8 in
1 in
1 in
50 mm
50 mm
Excess Gain Curve
Beam Pattern
1000
100
10
1
.01 m
.4 in
.1 m
3.9 in
1 m
39 in
10 m
Q85 Series long-range
diffuse mode sensors
E
X
C
E
S
S
G
A
I
N
DISTANCE
Range is referenced
to a 90% reflectance
white test card
.2 m
7.9 in
.4 m
16 in
.6 m
24 in
0 .8 m
31 in
0
25 mm
25 mm
Distance to 90% white test card
Q85 Series
long-range diffuse sensors
1 m
39 in
1 in
1 in
Excess Gain Curve
Long-range Diffuse Mode
Short-range Diffuse Mode
Sensing range: 3 inches (8 cm) to 15 feet (4,6 m) when used
with Banner model BRT-3 3-inch retroreflective target
Sensing beam: 680 nanometers, visible red (polarized)
Models:
Q85BW13LP (p/n 35564) no timing logic
optically-isolated SPST solid-state switch;
response time 4 milliseconds "on", 4 milliseconds "off"
repeatability 1 millisecond
Q85BW13LP-T9 (p/n 35563) with timing logic
optically-isolated SPST solid-state switch;
response time 10 milliseconds "on", 10 milliseconds "off"
repeatability 1 millisecond (with no timing in use)
Sensing range: 75 feet (23 meters)
Sensing beam: 680 nanometers, visible red
Effective beam diameter: 0.38 inches (9,6 mm)
Models:
Q853E emitter (p/n 31648) (use with either receiver, below)
Q85BW13R receiver (p/n 35572) no timing logic
optically-isolated SPST solid-state switch;
response time 6 milliseconds "on", 3 milliseconds "off"
repeatability 750 microseconds
Q85BW13R-T9 receiver (p/n 35571) with timing logic
optically-isolated SPST solid-state switch;
response time 12 milliseconds "on", 9 milliseconds "off"
repeatability 1 millisecond (with no timing in use)
