QM42 Series
Banner Engineering Corporation page 5
Quick Disconnect (QD) Cables
M12 x 1
ø15 mm
(0.6 in)
44 mm max.
(1.7 in)
The following is the selection of cables available for the QM42 QD models
DImensions Style Model Length For use with
4-pin
Euro Style
straight
MQDC-406
MQDC-415
MQDC-430 2 m (6.5 ft)
5 m (15 ft)
9 m (30 ft)
All QM42 sensors with
quick-disconnect fitting
Pin #2
White Wire
Pin #3
Blue Wire
Pin #4
Black Wire
Pin #1
Brown Wire
Pinout
38 mm max.
(1.5 in)
M12 x 1
ø15 mm
(0.6 in)
38 mm max.
(1.5 in)
4-pin
Euro Style
right-angle
MQDC-406RA
MQDC-415RA
MQDC-430RA 2 m (6.5 ft)
5 m (15 ft)
9 m (30 ft)
Sensors with NPN (Sinking) Outputs Sensors with PNP (Sourcing) Outputs
Cabled Models Cabled Models
Quick Disconnect Models Quick Disconnect Models
bu
bn
-
+
bk
wh
Load
Load
Load
Load
10-30V dc
bn
bu
-
+
bk
wh
Load
Load
10-30V dc
bu
bn
-
+
bk
wh
Load
Load
10-30V dc
bn
bu
-
+
bk
wh
10-30V dc
Load
Load
bn
bu
+
-
10-30V dc
DC Emitters
Cabled Models
bn
bu
10-30V dc
-
+
bk
wh
Quick Disconnect Models
Hookup Diagrams
