QM42 Series
page 4 Banner Engineering Corporation
20.1 mm
(0.79 in)
45.5 mm
(1.79 in)
2.5 mm
(0.10 in)
90º
20º
3.05 mm Slot
(0.120 in)
ø 3.05 mm
(0.120 in)
31.8 mm
(1.25 in)
5.1 mm R
(0.20 in)
24.1 mm R
(0.95 in)
15º (2)
CL 20.3 mm
(0.80 in)
3.1 mm R (2)
(0.12 in)
4.32 mm
Slot (2)
(0.170 in)
10º (Typ)
Dimensions
12.7 mm
(0.50 in)
23.9 mm (2)
(0.94 in)
ø 3.2 mm
(0.125 in)
(4 Holes)
27.1 mm (2)
(1.07 in)
42.0 mm
(1.65 in)
42.0 mm
(1.65 in)
Gain (Sensitivity) Adjustment (except emitters)
Green LED Power Indicator
Yellow LED
Output/Marginal Indicator
(Except emitters)
10.0 mm (0.39 in)
12.3 mm (0.48 in)
Threaded M4 x 0.7
Mounting Holes
42.0 mm
(1.65 in)
QM42FP Models All Other Models
45.9 mm
(1.81 in)
48.5 mm
(1.91 in)
12.7 mm
(0.50 in)
23.9 mm (2)
(0.94 in)
ø 3.2 mm
(0.13 in)
(4 Holes)
M12 x 1 x 18 mm
Euro-style
27.1 mm (2)
(1.07 in)
42.0 mm
(1.65 in)
42.0 mm
(1.65 in)
Gain (Sensitivity) Adjustment (except emitters)
Green LED Power Indicator
Yellow LED
Output/Marginal Indicator
(Except emitters)
60.2 mm
(2.37 in)
42.0 mm
(1.65 in)
45.9 mm
(1.81 in)
48.5 mm
(1.91 in)
QM42FP Models All Other Models
Cabled models
Quick-disconnect models
Accessory Mounting Bracket SMB19
Supplied with hardware
