3 Installation
IC equipment: Inline-Ultrafiltration
￭￭￭￭￭￭￭￭ 15
￭ Insert the ultrafiltration cell in such way that the screw heads are
located in the holes in the filtration cell holder provided for this
purpose.
Inserting the ultrafiltration cell in the ion chromatograph
Required accessories ￭ Filtration cell holder (6.2057.140)
￭ Ultrafiltration cell (6.2729.110)
1 Hanging in the holder
￭ Hang the filtration cell holder (6.2057.140) in the holding device
in the ion chromatograph provided for this purpose.
2 Inserting the ultrafiltration cell
￭ Insert the ultrafiltration cell in such way that the screw heads are
located in the holes in the filtration cell holder provided for this
purpose.
