2.3 Connectors of the ultrafiltration cell
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4 ￭￭￭￭￭￭￭￭
IC equipment: Inline-Ultrafiltration
3 Sealing ring 4 Lower chamber
5 Washers 6 Screws
For joining the upper and the lower part of
the cell.
2.3 Connectors of the ultrafiltration cell
Figure 3 Ultrafiltration cell – Connectors
1 Upper chamber 2 Lower chamber
3 Filtrate outlet
Labeled OUT. 4 Sample inlet
Labeled IN.
5 Sample outlet
Labeled OUT.
