3.3 Installation diagram
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
18 ￭￭￭￭￭￭￭￭
850 Professional IC –Anion – MSM-HC – MCS – Prep 2
3 PEEK pressure screw, short 6.2744.070 4 MSM-HC eluent inlet capillary
Labeled with Eluent. Connected to the col-
umn output.
5 MSM-HC eluent outlet capillary
Labeled with Detector. Connected to the
input of the MCS. 6 PEEK pressure screw, long 6.2744.090
7 Conductivity detector 8 Detector inlet capillary
Connected to the output of the MCS.
9 Detector outlet capillary 10 MSM-HC regeneration solution aspirat-
ing capillary 6.1803.020
11 Tubing olive 6.2744.034
For connecting capillaries to the aspiration
side of the peristaltic pump.
12 Pump tubing 6.1826.320
With orange/yellow stoppers. For the regen-
eration solution.
13 Pump tubing connection 6.2744.180
With safety device and filter. For connecting
capillaries to the outlet side of the peristaltic
pump.
14 MSM-HC regeneration solution inlet
capillary
Labeled with H2SO4.
15 MSM-HC regeneration solution outlet
capillary
Labeled with Waste.
16 MSM-HC rinsing solution aspirating
capillary 6.1803.020
17 Pump tubing 6.1826.320
With orange/yellow stoppers. For the rinsing
solution.
18 MSM-HC rinsing solution inlet capillary
Labeled with H2O.
19 MSM-HC rinsing solution outlet capil-
lary
Labeled with Waste.
20 MCS adsorption cartridges
21 Air aspirating capillary
For aspirating CO2-low air from the car-
tridges of the MCS.
22 Separation column
Matrix elimination with transfer procedure
This sample preparation technology is applied when the sample matrix
could damage the separation columns (and the analyte ion content is in
the ppm range).
For this, a small, defined sample amount is measured at the lower injec-
tion valve and is pumped with a transfer solution (ultra pure water) to the
preconcentration column at the upper injection valve . The sample is
retained by preconcentration column, while the matrix is rinsed into the
drain with the transfer solution. After a predefined time, the upper injec-
tion valve is switched to and data recording is started. The sam-
ple retained on the preconcentration column is now rinsed with the eluent
onto the separation column.
