3 Installation
850 Professional IC – Anion MSM-HC – MCS
￭￭￭￭￭￭￭￭
17
3
MSM-HC eluent inlet capillary
Labeled with Eluent. Connected to the col-
umn output.
4
MSM-HC eluent outlet capillary
Labeled with Detector. Connected to the
input of the MCS.
5
Detector inlet capillary
Connected to the output of the MCS.
6
Detector outlet capillary
7
Sample aspirating capillary 6.1803.040
Connected to the injection valve. Can be
connected to the sample degasser if the
sample matrix requires it.
8
Sample aspirating capillary 6.1803.040
Optional. Connection Sample Degasser –
Sample Processor.
9
Sample outlet capillary 6.1803.040
10 MSM-HC regeneration solution aspirat-
ing capillary 6.1803.020
11 Pump tubing 6.1826.320
With orange/yellow stoppers. For the regen-
eration solution.
12 MSM-HC regeneration solution inlet
capillary
Labeled with H2SO4.
13 MSM-HC regeneration solution outlet
capillary
Labeled with Waste.
14 MSM-HC rinsing solution aspirating
capillary 6.1803.020
15 Pump tubing 6.1826.320
With orange/yellow stoppers. For the rinsing
solution.
16 MSM-HC rinsing solution inlet capillary
Labeled with H2O.
17 MSM-HC rinsing solution outlet capil-
lary
Labeled with Waste.
18 PEEK pressure screw, short 6.2744.070
19 Tubing olive 6.2744.034
For connecting capillaries to the aspiration
side of the peristaltic pump.
20 Pump tubing connection 6.2744.180
With safety device and filter. For connecting
capillaries to the outlet side of the peristaltic
pump.
21 PEEK pressure screw, long 6.2744.090
22 Air aspirating capillary
For aspirating CO2-low air from the car-
tridges of the MCS.
23 Separation column
24 Conductivity detector
25 MCS adsorption cartridges
