3 Installation
881 Compact IC pro – Anion – MCS
￭￭￭￭￭￭￭￭
13
￭
Attach the CO
2
adsorption cartridge (6.2837.000) to the adsorp-
tion cartridge holder (6.2057.080) (see "Installing the adsorption
cartridges", page 57).
￭
Prepare the H
2
O adsorption cartridge (6.2837.010) (see leaflet to
the H
2
O adsorption cartridge) and attach it to the adsorption car-
tridge holder as well (see Figure 30, page 56).
￭
Plug the adapter (6.1808.190) onto the PVC tubing and connect
the two adsorption cartridges with one another (see Figure 30,
page 56).
￭
Place the adsorption cartridge (6.2057.080) holder in the detector
chamber.
￭
Connect the MCS air aspirating capillary (3-15) to the tip of the
CO
2
adsorption cartridge (6.2837.000).
8 Connecting the instrument
￭
Connect the instrument to a computer (see Chapter 3.19.1, page
58) on which the software MagIC Net™ is installed using the
USB cable (6.2151.020).
￭
Connect the instrument to the mains supply (see Chapter 3.19.2,
page 58).
9 Initial start-up
￭
Switch on the PC and start MagIC Net™.
￭
Switch on the instrument.
￭
Deaerate the high pressure pump (see Chapter 3.10.2, page
33).
￭
Set contact pressure of the peristaltic pump (see "Set flow rate",
page 50).
￭
Rinse the instrument without column with eluent for 5 minutes.
10 Installing guard and separation column
￭
Remove the coupling (6.2744.040) between the column inlet
capillary and the capillary of the MSM labeled with in.
￭
(Optional) Connect guard column (see Chapter 3.20, page 59)
– Fasten the guard column to the end of the column inlet
capillary (see leaflet to the guard column).
– Rinse the guard column with eluent for approx. 5 minutes.
