2.1 Starting Vision 
NIRS Vision Tutorial – Operation 
3
2 Getting Started
2.1 Starting Vision
Once the software is installed, a Vision Icon can be found on the desktop of
your computer.
1. Double click on .
2. In the Login dialog box, enter the following default login information:
 User ID NIRS
 Password NIRS
3. Press [Enter] or click on [OK].
2.2 Setting-up a Project
In Vision, a Project must be set up, before any data (instrument diagnostics or
spectral data) can be collected.
If this is your initial entry to Vision the Create New Project dialog box is
automatically opened. If the Create New Project dialog box is not open:
Open the Create New Project dialog box
1. Click on File  Project  New.
2. When asked to close the open project, click on [OK].
Define Project information
1. In the Create New Project dialog box enter the following information:
 Project ID “tutorial”
 Click on [OK]
 When asked “Create database C:\Vision\tutorial?” Click on [Yes].
Configure Data Sources
1. In the Configure Data Sources dialog box
 In the Instrument section, select Metrohm NIRS XDS-series
Instrument Driver
 Click on [Configure]
2. In the NIRSystem XDS-series Instrument Configuration window
 select the IP Address of your instrument
 Click on [OK]
