22 © 2014 DJI. All Rights Reserved.
Appendix
ESC Sound
ESC State Sound
Ready 1234567--B--B
Throttle stick is not at bottom BBBBBB…
Input signal abnormal B- - - - - - - - B- - - - - - - - B…
Input voltage abnormal BB- - - BB- - - BB- - - BB…
ESC LED
ESC State LED
Standby Off
Motor rotating Solid Red or Green On
Motor rotating at full throttle position Solid Yellow On
DJI ESCs are specifically designed for multi-rotors. When used with DJI autopilot systems
parameters and travel ranges do not have to be calibrated.
Specifications
Frame
Diagonal Wheelbase 900mm
Frame Arm Length 358mm
Frame Arm Weight
(with Motor, ESC, Propeller )
316g
Center Frame Diameter 272mm
Center Frame Weight (with Landing Gear
Mounting Base, Servos)
1185g
Landing Gear Size 460mm(Length)×450mm(Width)×360mm(Height)
Motor
Stator Size 41×14mm
KV 400rpm/V
Max Power 500W
