Clay Paky STORMY CC - Manual (Page 18)

18
PRELIMINARY
8. TECHNICAL DATA
TECHNICAL DATA
STORMY C71090
STORMY CC C71091
Led color temperature 5700K
Cooling Forced ventilation with axial fans.
User interface - LCD display 3 lines
- 4 Membrane buttons
Connection - AC power input/output: Neutrik PowerCon IP65
- DMX data in/out: 5-pin locking XLR
External power Full range 100-240V 50-60Hz, PowerCon connector
Input Power 850 VA
Body - Body extruded in black anodized aluminium
Weight 7.2 Kg (15.13 Ibs)
Protection rating IP20
Working position Work in any position
CE Marking CE Marking
Complies with the following European Directives
- 2006/95/EC (LVD)
- 2004/108/EC (EMC)
- 2011/65/EU (RoHS)
7.2 Kg
(15.13 Ibs)
462
(18.18")
152
(5.98")
305
(12.01")
303
(11.93")
