11
PRELIMINARY
5.1 SET-UP MENU
SET UP - DMX ADDRESS
It allows to set DMX address to be assigned to the projector, it’s possible to select a DMX address
between 1 and 512.
> NOTE: : In case of absence of DMX input signal, the displayed projector address flashes.
SET UP - CHANNEL MODE
It allows to set the operation mode of the projector selecting from the following:
• Standard Max 7 DMX channels occupied for Stormy CC / max 3 DMX channels occupied for
Stormy
• Extended Max 10 DMX channels occupied for Stormy CC / max 6 DMX channels occupied for
Stormy.
SET UP – FIXTURE ID
It allows to set a "Fixture ID" to be assigned to the projector, for easier identifcation of the same
projector in an installation. It’s possible to select a "Fixture ID" between 1 and 255.
STORMY C71090
STORMY CC C71091
