— 7
and Run or Slope.

Enters, calculates or stores the Offset (Rise).

Enters or calculates the Run.

Enters or calculates the Travel (Diagonal). Used to
calculate pipe length.

Defines the pipe material used for various pipe
sizes used in Pressure Loss calculations.

Defines the nominal Pipe Size being used.
 
Defines the Pipe Type based on Pipe Material.

Enter or calculate volumetric Flow Rate through
a Pipe.
 
(Velocity) – Enter or calculate Velocity and convert
between feet per second, feet per minute and
meters per second.

Enter value for Force/Area calculations. Calculate
Pressure Loss. Convert between units of pressure.

Calculate Force and convert between lbf, newton.

Enter for Flow, Velocity, Pressure, Force
calculations. Calculate Area given values for Flow/
Velocity or Force/Area. If a Pipe Size has been
selected, Area will match Inside Dimension for pipe
of the current material and type.
miscellaneous functions
 
Displays value of
π
(3.141593).
 
(+/–) Toggle displayed value between minus and
plus value.
 
Clear All – Returns all stored values to the default
settings. (Does not affect Preference settings.)
  Square root function
