U
ser
’
s
G
Uide
— 21
KEySTRoKE DISPlAy

 0.
1. Enter Run:
   
RuN 24 INch
2. Enter bend angle:
  
/0 45.00°
3. Find the Travel:

33 15/16 INch
4. Subtract 2 times the elbow take out (2 x 3 ¾”) from the
calculated centerline Travel:
        
26 7/16 INch
5. Subtract 2 times the welder’s gap (2 x 3/32”):
       
26 1/4 INch
calculating Pipe Drop (offset)
Find the slope of a Pipe Run if it drops 6 Inches over 50 Feet.
What is its Angle and Percent Grade?
KEySTRoKES DISPlAy

 0.
1. Enter the Run:

   RuN 50 fEET 0 INch
2. Enter the Offset:

  ofST 6 INch
3. Calculate the Percent Grade, Slope and Angle:

 % GRD 1.

GRD 0.01

SlP 0 - 1/8 INch

<Ø 0.57º
