28 — P
iPe
T
rades
P
ro
™
 (Schedule 80) TYPE 80 PLAStIC
 (Schedule 120) TYPE 120 PLAStIC
 (SDR 21) TYPE SD21 PLAStIC

(SDR 26) TYPE SD26 PLAStIC

(SDR 32.5) TYPE SD32 PLAStIC
 (SDR 41) TYPE SD41 PLAStIC
You can also directly enter a Pipe Type, e.g., Schedule 80, by
entering a number corresponding to the pipe type.
KEYSTROKE DISPLAY

 0.

MATL PLAStIC

   TYPE 80 PLAStIC
Pipe Size Key
When you have chosen a Pipe Material and Type and then
enter Pipe Size, the pipe data will be displayed.
For this example we are using 3" Steel, Schedule 80 pipe.
KEYSTROKE DISPLAY
 
0.
1. Choose the Pipe Material:

MATL StEEL
2. Enter the Pipe Type:

   TYPE 80 StEEL
3. Enter the Pipe Size:

 3 INCH
4. Toggle through the Pipe data:

80 SIZE 3 INCH

(Outside Diameter) OD SIZE 3.5 INCH

(Internal Diameter) ID SIZE 2.9 INCH

(Wall Thickness) THK SIZE 0.3 INCH
(cont'd)
(cont'd)
KEYSTROKE DISPLAY
