P

OCKET

R

EFERENCE

G

UIDE

— 5

Trigonometric Keys (

TRIG MODEL

#4080)

S

Finds the sine of a degree
or undimensioned value.

Ç S

Arcsine (sin

-1

) — Gives the

angle for the Sine value.

ç

Finds the Cosine.

З з

Arccosine (cos

-1

)

Gives the angle for the
Cosine value.

t

Finds the Tangent.

Ç t

Arctangent (tan

-1

)

Gives the angle for the
Tangent value.

Right Triangle/Roof Framing Keys

p

Enters or calculates the
slope (amount of “Rise”
over 12” of “Run”.

Ç p

Slope — Enters a Pitch
ratio, or slope (e.g.,

• 5

8 3 Ç p

).

r

Enters or calculates the ver-
tical leg of a right triangle.

Ç r

Rake-Wall — Finds the
stud sizes based on entered
right triangle values.
