P

OCKET

R

EFERENCE

G

UIDE

— 28

Rake-Wall –

No Base

Find each stud size in a Rake-Wall with a
peak of 3 Feet 6 Inches, and a length of
5 Feet. Use 16 Inches as your On-center
spacing (default; already stored):

KEYSTROKE

DISPLAY

1. Enter Rise and Run:

o o

0.

3 f 6 i r

RISE 3

FEET

6

INCH

5 f R

RUN 5

FEET

0

INCH

2. Find stud lengths:

Ç r

(R/Wall)

RWOC

16

INCH

r

RW 1 2

FEET

6-13/16

INCH

r

RW 2 1

FEET

7-5/8

INCH

r

RW 3 0

FEET

8-3/8

INCH

r

BASE 0

FEET

0

INCH

3. Find Rake-Wall angle of incline:

r

RW 34.99°

STORED
