Regular Hip/Valley and Jack Rafters
A roof’s Pitch is 9/12 and half the total
span is 6 Feet. Find the lengths of the
Common, Hip/Valley and Jack rafters.
Also find the incremental jack adjustment
and the cut angles. (Jack rafters at 16”
On-center spacing.)
KEYSTROKE DISPLAY
1. Find the Common rafter length:
o o 0.
6 f R RUN 6
FEET
0
INCH
9 i p PTCH 9
INCH
d (Common) DIAG 7
FEET
6
INCH
2. Find the Hip/Valley rafter length and
cut angles; then the incremental jack
adjustment, Jack rafter lengths and cut
angles:
H H/V 9
FEET
7-1/4
INCH
H PLMB 27.94°
H LEVL 62.06°
H CHK1 45.00°
j JKOC 16
INCH
j INCR 1
FEET
8
INCH
j JK 1 5
FEET
10
INCH
j JK 2 4
FEET
2
INCH
j JK 3 2
FEET
6
INCH
STORED
