Calculated Industries 4065 v3.1 Pocket Reference Guide Construction Master Pro User Manual

Page 29

background image

P

OCKET

R

EFERENCE

G

UIDE

— 25

KEYSTROKE

DISPLAY

1. Use trigonometry formula (divide the
rise by the hypotenuse):

o o

0.

6 f ÷ 1 0 f =

0.6

2. Solve for angle or degrees:minutes:sec-
onds:

З з

(cos

-1

)

53.13°

Ç •

(dms

deg)

DMS 53.07.48

Common Rafter Length

Find the point-to-point length of the
Common rafter on a 7/12-pitched roof
with a span of 28 Feet. What are the
angle cuts?

KEYSTROKE

DISPLAY

1. Enter Pitch:

o o

0.

7 i p

PTCH 7

INCH

2. Enter half the span as the run:

2 8 f ÷ 2 =

14

FEET

0

INCH

R

RUN 14

FEET

0

INCH

3. Find the Common and cuts:

d

DIAG 16

FEET

2-1/2

INCH

d

PLMB 30.26°

d

LEVL 59.74°
