37
7. S
PECIFICATIONS
Powerline Wireless N Extender
WLAN: IEEE 802.11 b/g, IEEE 802.11n
LAN: IEEE 802.3, IEEE 802.3u
Standards
Powerline: HomePlug AV 1.0
WLAN to Ethernet: up to 93 Mbps (Under 802.11n 40MHz) Maximum
Throughput
Powerline to Ethernet: TCP: 92 Mbps
WLAN: 2.4~2.4835GHz
Frequency band
PLC: 2~ 68MHz
RF Power:
802.11b TX: 16 dBm +/- 1.5dB (typ.)@1Mbps
802.11g TX : 16 dBm +/- 1.5dB (typ.)@6Mbps
802.11n TX : 14 dBm +/- 1.5dB (typ.)@6.5Mbps
802.11n TX : 13 dBm +/- 1.5dB (typ.)@13.5Mbps
Sensitivity:
802.11b RX: ­82 dBm(typ.)@11Mbps
802.11g RX: ­70 dBm(typ.)@54Mbps
802.11n RX(20MHz): ­67dBm(typ.)@ 72.2Mbps
802.11n RX(40MHz): ­64dBm(typ.)@ 150Mbps
Physical Data Rate:
802.11b: 1,2, 5.5, 11Mbps
802.11g: 6, 9, 12, 18, 24, 36, 48, 54Mbps
802.11n (20MHz): MCS0~7, Up to 72.2Mbps
WLAN transceiver
spec
802.11n (40MHz): MCS0~7, Up to 150Mbps
Wi-Fi mode Wireless AP+ Bridge mode (Default)
WLAN
WPS PBC / PIN code, WPA ‐PSK, and WPA2‐PSK
Security mode
PLC
128 ‐bit AES
Antenna type 1T1R
LAN port 1 port
AC input 100 - 240 V
50 ‐60Hz
Power consumption
(Note: Ethernet and Wi ‐Fi is connected and running)
