27
5.4.4 WPS (Wi-Fi Protected Setup)
This function helps to establish the Wi-Fi security. For AP mode, it can be setup one WPS
method including PIN (Personal Identification Number) and PBC (Push Button Certification).
To begin the WPS progress, the WLAN security must be setup first. Please setup one
among WPAPSK, WPA2PSK, WPA/WPA2PSK and then apply WPS setting. WPS will only
be available in these encryption types.
PIN: query the PIN code in the utility of the WLAN client connecting to this AP, and then
enter it in the PIN field. The Wi-Fi link between the WLAN client and the device should be
encrypted.
PBC: Select PBC, and then you can begin the PBC process. Press the PBC button in the
front panel can also trigger this process. Press or click the PBC button on the WLAN client
to finish the communication. You can press the PBC button on the WLAN client first and
then click the PBC button on this device to establish the encryption.
The options and the information fields are showed below.
WPS Config
Item Description
WPS Capable Select enable then press Apply button to start this function.
NOTE：WPS will be available only with the two conditions:
1、WPA-PSK, WPA2-PSK or WPA/WPA2-PSK is set
2、Hidden SSID is disabled.
