2. INTRODUCTION
2.1 Features
• DMX512/1990
Standard
• Controls
8
fi xtures of up to 4 channels, totally 32 channels
•
4 preset scene/color banks, 8 scenes/colors per bank, total of 32
possible presets
•
Record up to 8 chases with up to 32 scenes per chase
•
4 sliders for direct control of channels
•
Built-in microphone for music mode
•
Auto mode program controlled by fade time sliders
•
DMX out: 3-pin XLR
•
LED information display
•
Blackout function and instant strobe with variable speed fader
2.2 General
Overview
The controller is a universal intelligent lighting controller. It allows the
control of 8 fi xtures composed of 4 channels each and up to 256 program-
mable scenes. Eight chase banks can contain up to 32 steps composed of
the saved scenes and in any order. Programs can be triggered by music,
automatically or manually. All chases can be executed at the same time.
On the surface you will fi nd various programming tools such as 4 universal
channel sliders, quick access fi xture and scene buttons, and an LED display
indicator for easier navigation of controls and menu functions.
2.3 Nifty, Spiffy Diagram (front)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
