— 25 —

SYM. DESCRIPTION
TB

Terminal Block

GL

Ground Lug

MC

25A Motor Contactor

OL

Overload Relay

MTR

1.5 HP Motor 208-240/480V, 3 PH, 60Hz

1.5 HP Motor 115/230V, 1 PH, 60Hz

CT

.150 KVA Transformer

MC-A

Auxiliary Contact Block (3-phase only)

FH

Fuse Holder

FU

1.6A Fuse

SW-2

Toggle Switch (On-Off-Momentary)

DS

Door Switch

PB

Pushbutton (Start)

TR

Timer, 60-Sec. (3 cams)

1LT

Cycle Light (Amber)

2LT

Power Light (Red)

TAS-1 Thermostat
SOL

Solenoid Valve

HC

Contactor (Elec. Tank Heat)

HTR

3KV Immersion Heater

GC

Gas Control (LP or Nat.)

SSOL

Solenoid Valve (Steam)

LWC

Low Water Cutoff

TAS-2

Thermostat (High Limit)

TM

Auto Fill Timer, 3-Min.

SW 3&4 Toggle Switch (On-Off)
CR1 Relay

1. All wires are identified with wire markers.

2. Line, motor circuit and immersion heater wires are

#12 AWG Black, type MTW, 105 C, 600 V.

3. Control circuit wires are 16 AWG Red, type MTW,

105 C, 600 V.

4, TR-1 is a cam switch located next to the Timer

Motor TR.

5. Numbers in the square boxes

are Booster

Control circuit connection points.

6.

indicates optional feature.
