Power Sensors
Power Sensors, for use with Models 4201A503 and 4201A504 Series Wattmeters,
currently available are listed below.
Specifications
Model FWD Max. Power RFL Max. Power Frequency Range
4152-220 150 W 15 W 30-88 MHz
4163-240 150 W 15 W 118-250 MHz
4164-240 150 W 15 W 420-512 MHz
4169-300 60 W 6 W 805-960 MHz
Insertion VSWR 1.1 max.
Insertion Loss 0.2 dB
Directivity 25 dB min.
Accuracy ± 5% of full scale
Connectors:
RF Input
RF Output
DC Outputs
Female N
Female N
Solder Lugs
Finish Grey Powder Coat
Nominal Size
(Including connector) 4-1/2" W x 1-1/4" H x 1" D
(114 mm x 32 mm x 25 mm)
Nominal Weight 4.5 oz. (128 grams)
