Hand-held digital power meter, 5000-xt

Hand-Held Digital
Power Meter
5000-XT
The hand-held digital power meter has been completely redesigned with the new Bird® 5000-XT.
Ideally suited for field techs and engineers who need to make power measurements anywhere they
go, the 5000-XT’s new user interface has an intuitive, menu-driven design, making it the easiest to
use on the market. It’s operable even with one hand and compatible with all our field and legacy sensors.
}
Rugged field meter tested to military standards
}
Works with most Bird field sensors
}
Up to 60 hours of continuous battery life
}
Automatically detects sensor and displays appropriate screen
}
Data logging with up to 7 days of onboard memory
APPLICATIONS
Signals Measured: WiMAX, (IEEE 802.16), GSM/EDGE,
W-CDMA, LTE, WiFi (802.11), HSUPA/HSDPA,TD-SCDMA,
TETRA, P25, Zigbee (IEEE 802.15), Bluetooth, RFID, DVB, DMB
and MediaFlo.
Measurements performed: VSWR, peak power, true
average power, crest factor, CCDF and burst power.
Sensors supported: 14
Display languages: English, Spanish and Chinese
PROBLEMS
}
SOLUTIONS
Poor lighting or bright light
}
Indoor/outdoor viewable monochrome VGA display with backlight.
Lack of access to AC
}
Up to 60 hours of continuous use battery life.
Physically demanding environments
}
Single key allows one-hand toggling through operations.
}
Locking mechanism prevents unintentional sensor disconnects.
}
Compliant with MIL spec drop test.
}
Light weight at only 1.4 lbs.
Varying field tech skill levels
}
Multiple measures to identify failure mode.
Need for power measurement comparison
}
Data logging capability with 1 GB of memory, storing and transfer
of up to 7 days of data.
