4240-156

440-960 MHz

4308-1

50 W

ELECTRONIC

1.5

5

15

50

TRANSIT

1-5/16

RUBBER FEET (4)

3-3/8

3-5/8

3-29/32

(33mm)

(99mm)

(92mm)

(86mm)

4"

(101mm)

6-7/8

(175mm)

1-3/4

(44mm)

Q.C. CONNECTOR

RUBBER FEET(4)

Figure 1

Model 4308 Outline Drawing

Bird Model 4308 Thruline Wattmeter

"
