Maintenance
21
Replacement Parts
Bird 8730A, 8732A, and 8738A
Bird 8731
Bird 8738A110
Interlock (Optional)
Description Qty Part No.
Resistor Assembly 1 8738A072
Water Chamber Assembly 1 8738A052
Hose Connector 2 5-065-2
Housing, Rear 1 8738A071
Housing, Front 1 8738A054
Socket Head Cap Screw, 8-32 x
3 ⁄
4
" 5 1118-1208-00
Socket Set Screw, 10-32 x
1 ⁄
4
" Cone pt. 1 1129-0400-25
Socket Head Cap Screw,
1 ⁄
4
-20 x
3 ⁄
4
" 6 1121-1208-00
Center Conductor Assembly
8732A
8730A
8738A
1
8732A053
8730A053
8738A056
Outer Conductor Assembly
8732A
8730A
8738A
1
8732A052
8730A052
8738A053
7/16 Jack, IEC Type 169-4 (8732A only) 1 4240-344
Description Qty Part No.
Water Chamber Assembly 1 8731-003
Center Conductor Assembly (includes resistor) 1 8731-005
Outer Conductor Assembly 1 8731-004
Description Qty Part No.
Hose Connector 2 5A2857-1
Center Conductor Assembly 1 8738A113
Outer Conductor Assembly 1 8738A112
Description Qty Part No.
Flow Switch 1 5-898-6
Interlock Control Assembly
115 Vac
230 Vac
1
8750-101-1
8750-101-2
Interlock Control Assembly Components
Relay Clamp 1 8630-193
Time Delay Relay
115 Vac
230 Vac
1
5-1664
5-1665
Indicator Light
115 Vac
230 Vac
1
5-970-1
5-970-2
Thermoswitch (8732A Only)
Opens at 79 °C
Opens at 72 °C
1
2450-095-3
2450-095-1
