Bird 8578 Series RF Load Resistor
12
Shutting Down
1. Turn the transmitter off.
2. Disconnect the RF line.
3. Allow the fan motor to continue running for a few minutes to allow the
resistive elements and the surface to cool.
4. Remove AC power.
Measuring and Monitoring RF Power
The Models 8578A100, 8578B100, 8578A150, and 8578B150 Load Resistors
may be used in conjunction with any one of the various Bird rigid coaxial line
Thruline
®
Wattmeters. When fitted with the appropriate line section and
wattmeter, either model becomes a useful tool for tuning and adjusting a
transmitter as well as monitoring RF power directly in watts. Call a Bird
Sales office for more information about Thruline wattmeters. See “Customer
Service” on page 19.
WARNING
Do not touch the surface of the load. The surface may become hot when
power is applied to load.
