Bird Model 8000 Series Termaline Coaxial Load Resistor

4

BIRD

ELECTRONIC

CORP.

4240-063

1-3/4

(44mm)
Square

4-1/4

(108mm)

57/64
(23mm)

Male N "QC" Connector

CO

AXIAL
RESISTOR

Figure 1

Model 8085 Outline Drawing
