Specifications
Impedance 50 ohms nominal
Ambient Temperature -40°C to +45°C
(-40°F to +113°F)
Cooling Method Convection air currents
Operating Position Any ††
MODEL
MAX. VSWR
CONNS.
MAX.
WATTS
FREQ.
MHz SIZE
WT. OZ.
8080 1.1 dc-1000
1.25 1000-3500 N-M† 25 dc-3500 5-9/64"L x 1-1/4"sq
(130.6 x 31.8 mm) 9
(225g)
8085 1.1 dc-1000 N-M† 50 dc-3500 5-9/64"L x 1-3/4"sq 15
(425g)
8163 (Similar to Model 8164, see Installation, Chapter 2)
8164 1.1 dc-1000
1.2 1000-2500 N-F† 100 dc-2400 6-63/64"L x
2-3/4"sq
(177.4 x 69.9 mm) 48
(1.36 kg)
8166 1.1 dc-1000
1.2 1000-2500 N-M† 150 dc-2500 7-31/64"L x 4"sq
(190 x 101.6 mm) 96
(1.36 kg)
8173 1.1 dc-1000
1.25 1000-2000 N-F† 300 dc-2000 9"L x 9-9/16"H x
5-1/8"W
(228.6 x 242.9 x
130.2 mm) 100
(2.84 kg)
8431 1.1 dc-1000 N-F* 500/600 dc-2500 13-7/64"L x 7-1/8"H
x 9-1/4"W
(333 x 181 x 235
mm) 206
(5.9 kg)
†“QC” Connector
* “SQC” Connector
†† See Text
