Fault Codes
10
1
009/003
Short circuit from the release solenoid to voltage.
Left Rear Axle PMV.
10
2
009/004
Short circuit from the release solenoid to ground.
10
3
009/005
Open circuit at the release solenoid.
10
4
009/005
Open circuit on the common line to the valve.
10
5
009/003
Short circuit from the hold solenoid to voltage.
10
6
009/004
Short circuit from the hold solenoid to ground.
10
7
009/005
Open circuit at the hold solenoid.
Left Rear Axle PMV (cont.).
10
8
009/002
System configuration is incorrect.
10 or 11
9
014/003
Common side of valves – stray voltage detected.
PMV Commons.
10 or 11
10
014/003
Common side of valves shorted high.
10 or 11
11
014/004
Common side of the valves shorted to ground.
11
1
010/003
Short circuit from the release solenoid to voltage.
Right Rear Axle PMV.
11
2
010/004
Short circuit from the release solenoid to ground.
11
3
010/005
Open circuit at the release solenoid.
11
4
010/005
Open circuit on the common line to the valve.
11
5
010/003
Short circuit from the hold solenoid to voltage.
11
6
010/004
Short circuit from the hold solenoid to ground.
11
7
010/005
Open circuit at the hold solenoid.
11
8
010/002
System configuration is incorrect.
12
1
011/003
Short circuit from the release solenoid to voltage
Left Rear Axle PMV.
12
2
011/004
Short circuit from the release solenoid to ground.
12
3
011/005
Open circuit at the release solenoid.
12
4
011/005
Open circuit on the common line to the valve.
12
5
011/003
Short circuit from the hold solenoid to voltage.
12
6
011/004
Short circuit from the hold solenoid to ground.
12
7
011/005
Open circuit at the hold solenoid.
12
8
011/002
System configuration is incorrect.
13
1
012/003
Short circuit from the release solenoid to voltage.
Right Rear Axle PMV.
13
2
012/004
Short circuit from the release solenoid to ground.
13
3
012/005
Open circuit at the release solenoid.
13
4
012/005
Open circuit on the common line to the valve.
13
5
012/003
Short circuit from the hold solenoid to voltage.
13
6
012/004
Short circuit from the hold solenoid to ground.
13
7
012/005
Open circuit at the hold solenoid.
13
8
012/002
System configuration is incorrect.
Blink Codes
1st.
2nd.
Description
Location
MID 136
SID/FMI
