Bendix Commercial Vehicle Systems TABS-6 ADVANCED MC SD SHEET - Manual (Page 27)

27
FIGURE 22 - bendix ® tAbS-6 ™ Adv mc module - 2S/2m Side contRol (0 deGRee) AbS electRicAl & AiR SYStem
FIGURE 23 - bendix tAbS-6 Adv mc module - 2S/2m Side contRol (180 deGRee) AbS electRicAl & AiR SYStem
Troubleshooting: System Schematics
2S/2M - SIDE CONTROL - Fixed Axles
0 Degree Mounting Orientation
Ignition
Power
Trailer Chassis Harness
Bendix ®
TABS-6 ™
Advanced
Multi-Channel
Bendix ®
SR-5 ™ Trailer
Spring Brake
Valve
Trailer ABS Pigtail Harness
ABS Indicator Lamp
5-Pin ABS
Connector
Supply Line
Control Line
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
Left - “Road-Side”
7-Pin SAE J560
Connector
P21
P22
Brake Lamp Power
Ground
“S-D”
“S-C”
Bendix ® WS-24 ™ Wheel Speed Sensor
Bendix ® WS-24 ™ Wheel Speed Sensor
Air Bellow
(where used)
Load Sensor
(where used)
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
2S/2M - SIDE CONTROL - Fixed Axles
180 Degree Mounting Orientation
ABS
Ignition
Power
Trailer Chassis Harness
Bendix ®
TABS-6 ™
Advanced
Multi-Channel
Bendix ®
SR-5 ™ Trailer
Spring Brake
Valve
Trailer ABS Pigtail Harness
ABS Indicator Lamp
5-Pin ABS
Connector
Supply Line
Control Line
Right - “Curb-Side”
Semi-Trailer Tandem Axle Trailer
Left - “Road-Side”
7-Pin SAE J560
Connector
Brake Lamp Power
Ground
“S-C”
“S-D”
Bendix ® WS-24 ™ Wheel Speed Sensor
Bendix ® WS-24 ™ Wheel Speed Sensor
P21
P22
Air Bellow
(where used)
Load Sensor
(where used)
A Brake Lamp Power
B Ignition Power
C NC
D Indicator Lamp
E Ground
